4x2500 CNC Hydraulic Shearing Machine With E200Ps QC12K Series

4x2500 CNC Hydraulic Guillotine Shear With E200Ps QC12K Series and Laser Cutter Steel frames are over 600⁰ annealed to relieve stress, they will not deform after years of heavy use.

Product Description

Brand: Anhui Xiyuan Machine       Origin: China
Shipping time: 30 days       Availability: 30 set/month

Features of 4x2500 CNC Hydraulic Guillotine Shear With E200Ps QC12K Series

  •  Less waste and less maintenance
  •  High performance
  • Same job, 50% less energy
  • High dynamic Y-axis control
  • Productivity increased by more than 30%
  • CNC DELEM DA53T 2D color graphics
  • ACCURL® BGA-2 for X=500mm X,R-Axis
  •  Kit: 4 V die (V=16-22-35-50) series 835mm punch
  •  ACCURL Pro Manual Wave Crowning System
  • GIVI Optical Scale
  •  Lazer Safe Dual Beam Photocell
  • HOERBIGER (HAWEI) hydraulic system
  • High-efficiency motor - IE3 class
  • Electrical cabinets of Schneider and Siemens components





The basic composition of CNC Hydraulic Guillotine Shear

The basic components of 4x2500 CNC Hydraulic Shearing Machine and 6×4000 CNC Guillotine Shearing Machine include machining program, input device, CNC system, servo system, auxiliary control device, feedback system and machine body. The processing program can be written manually, and the complex processing requirements can be drawn on the computer and then generated. The input of the program can be manually input through the numerical control system panel, transmitted through the cable through the computer communication port, or transmitted through the computer USB interface.



Specific accessories of CNC Hydraulic Guillotine Shear

First, there are some accessories in the circuit, which generally include: various buttons, indicators, control contacts etc., transformers, switches, motors, etc.

The second is the hydraulic system accessories of the hydraulic guillotine shearing machine. Generally, there are oil pump, valves of various specifications, pressure gauges and their switches, level gauges, oil pipe fittings, seals, etc.

Finally, there are other mechanical accessories of the hydraulic guillotine shearing machine, including blades, bearings, tool holders, bolts of various types and specifications, gears, optical rods, etc.





8 qc12k 4x2500 cnc hydraulic sh 5

Heat treatment process



Qc12k Swing Beam Cutting Machine With E21s Sheet Bending Machine and Laser Cutter Steel frames are over 600⁰ annealed to relieve stress, they will not deform after years of heavy use.



mechanical process



The frame is heat treated to relieve welding stress. The Qc12k Swing Beam Cutting Machine With E21s Sheet and Laser Cutter Frame is machined on a 5-axis CNC machining center with single reference fixation. This keeps all axes parallel and the machine surface is precise, giving the machine extreme precision and longevity.



CNC Hydraulic Guillotine Shear  Engineering Design



Hydraulic has extensive experience in developing and designing components with very tight tolerances using SOLIDWORKS 3D CAD modeling technology, and Hydraulic engineers are competent in the first-principles computational design of the Qc12k Swing Beam Cutting Machine With E21s Sheet. The design and analysis experience of computer-aided engineering (CAE) for heavy industry is novel to traditional companies in preparation for the implementation of the Fourth Industrial Revolution.



Finite Element Analysis and Stress Analysis



The CAE software SOLIDWORKS is used as a method for analyzing the linear static structure, stress, and deformation of the frames of press brakes and laser cutters. Therefore, for complex structures, highly complex loads, transient modeling, and combinations of the above, FEA makes sense.





A few notes on the operation of the hydraulic guillotine shearing machine



  • When assigning work tasks, the workshop supervisor should clearly explain to the operator the processing precautions of the product and the quality requirements of the product according to the skills and experience of the shearing machine operator.
  • After receiving the production task assigned by the workshop supervisor, the operator must refuel according to the lubrication system. Test operation can only be carried out after checking that the protection and signaling devices of the machine tool are intact and reliable.
  • Do not allow 4x2500 CNC Hydraulic Shearing Machine With E200Ps QC12K Series to cut extra-thick, hardened steel, high-speed steel, alloy tool steel, cast iron, and brittle materials.
  • After changing the blade, adjust the edge gap according to the thickness of the material. The blade should be firmly fastened. After the blade is fastened, it should be climbed and tested for a stroke to avoid edge impact and damage to the machine tool.
  • Pay attention to the safety of your fingers when feeding, especially when a plate is cut to the end, do not pad your fingers under the plate to feed or feed your fingers into the cutting edge. The last section of the material head is not enough 200mm and is not allowed to be cut. It is strictly forbidden for two people to cut two pieces of material at the same time on the same cutting machine.
  • The machine tool is not allowed to be repaired or rubbed while driving, and no tools or other objects are allowed on the machine table of the hydraulic guillotine shearing machine.
  • The equipment shall be under the responsibility of a special person and may not be used arbitrarily without approval.
  • After the work is finished, the power should be cut off, the machine tool cleaned, and the place of work should be cleaned.



Use and maintenance of shears



  • Strictly follow the operating procedures to operate the 4x2500 CNC Hydraulic Guillotine Shear With E200Ps QC12K Series.
  • add lubricating oil regularly, fixedly, and quantitatively according to the requirements of the lubrication chart before each start of the machine. The oil should be clean and free of precipitation.
  • The machine tool must be kept clean frequently, and the parts that are not painted are rust-proof and greasy.
  • The lubricating oil in the motor bearing should be replaced and refilled regularly, and frequently check whether the electrical part normally works safely and reliably.
  • Regularly check whether the triangle belt, handle, knob, and button are damaged. If the wear is severe, replace it in time, and report spare parts for replacement.
  • Regularly check the hydraulic guillotine shearing machine to repair switches, insurance, and handles, and ensure that it works reliably.
  • Lubricate and scrub the machine tool 10 minutes before work every day.
  • It is strictly forbidden for non-designated personnel to operate the 4x2500 CNC Hydraulic Shearing Machine With E200Ps QC12K Series. Normally, people must stop the machine.



8 qc12k 4x2500 cnc hydraulic sh 4



8 qc12k 4x2500 数控液压 sh 5



8 qc12k 4x2500 数控液压 sh 4





8 qc12k 4x2500 数控液压 sh 3



Company Profile

 Maanshan Xiyuan Machinery Technology Co., Ltd. is located in Maanshan City, Anhui Province. We specialize in R&D, production and sales of metalworking machine tools, including bending, cutting, shearing, grooving and punching. We look forward to cooperating with end users and distributors with our good quality, service and price. Our brand is named Xiyuan, we also welcome OEM, ODM orders. Let us be your business support and you will have no problems with machine delivery operation and installation. We guarantee full assistance and guidance.

milling cutters g4d4896a8d 640

FAQ about the company

Ma’anshan Xiyuan Machinery Technology Co., Ltd is a machine tool manufacturing, bending mold, and mechanical cutting production as one of the production bases.
The company is located in the southeast gateway of Anhui Province, next to Nanjing Lukou Airport, in the developed Yangtze River Delta area, with well-developed transportation and fast transportation.

We have standard product for shearing machine/punching machine/Press brake/laser cutting machine , we will reply you quickly with the quotation for such kind of product. We also focus on the customized and both developed product,  the quotation will be sent after mutual discussion for detailed requirement.

You can get in touch with us through the form on the page or contact information (tel:+ 86 18298207106 mail:JackLei@WDXIYUAN.email.cn). We will respond to your questions as soon as we see your message.

When you need to modify your order, please communicate with our sales staff to confirm your latest needs and draw up a new contract based on your needs. We will produce products according to your needs.

When you need to modify your order, please communicate with our sales staff to confirm your latest needs and draw up a new contract based on your needs. We will produce products according to your needs.

The company is located in the southeast gateway of Anhui Province, close to Nanjing Lukou Airport, and is located in the developed Yangtze River Delta region, with well-developed and fast traffic. Due to the particularity of the product, we generally choose to ship by sea. If you have special needs, you can communicate with us.

Before delivery, we will send you the pictures and videos for you to check the machine quality.And also you can arrange for quality checking by yourself or by your contacts in China.
